When designing or upgrading a fire protection system, one of the most critical decisions is determining the appropriate size of the fire water tank. Whether for industrial plants, commercial buildings, warehouses, or remote sites, having an adequately sized fire water storage tank ensures that sufficient water is available during emergencies. Undersized tanks can compromise safety, while oversized tanks may result in unnecessary costs.

This guide provides a detailed, step-by-step approach to calculating fire water tank capacity, helping engineers, facility managers, and developers make informed decisions in line with fire codes and operational requirements.



Why Fire Water Tank Sizing Matters

The fire water tank is the backbone of many firefighting systems, particularly in areas without access to a reliable municipal water supply. Its primary role is to supply water for firefighting during the critical initial minutes of a fire event, especially when fire department response may be delayed.

An incorrectly sized tank can lead to:

• Insufficient water supply during fire suppression
• Non-compliance with fire safety codes (NFPA, FM, local regulations)
• Operational challenges for pump systems
• Higher capital and maintenance costs


Step 1: Understand the Types of Fire Water Demand

Fire water tanks are typically sized based on two main components of demand:

• Fire Flow Rate: The required rate of water supply during a fire event, usually measured in gallons per minute or liters per second.
• Duration of Supply: The amount of time the water must be available at the required flow rate.

Fire codes such as NFPA 22 or local authority guidelines often define both flow rate and duration based on risk classification, occupancy type, and building size.



Step 2: Identify Fire Protection System Requirements

Start by determining the design requirements of your facility. This includes:

• Building type and hazard classification
  (e.g., light hazard, ordinary hazard, high hazard)
• Fire suppression method
  (e.g., fire hydrants, sprinklers, foam systems)
• Fire code requirements
  Refer to local fire codes, NFPA standards, or insurance mandates. For instance:
  • NFPA 13 for sprinkler systems
  • NFPA 14 for standpipes
  • NFPA 20 for fire pumps
  • NFPA 22 for water Storage Tanks



Step 3: Calculate Fire Flow Demand

The most common method is to multiply the required flow rate by the required duration.

Formula:
Tank Capacity (Liters or Gallons) = Fire Flow Rate × Duration

Example:
Fire Flow Rate = 1,000 gallons per minute (GPM)
Required Duration = 60 minutes
Total Tank Volume = 1,000 GPM × 60 minutes = 60,000 gallons

This is the minimum usable capacity required in the tank.

If using the metric system:

Fire Flow Rate = 20 liters per second
Duration = 60 minutes = 3600 seconds
Tank Volume = 20 L/s × 3600 s = 72,000 liters



Step 4: Add Reserve Volumes

Many facilities need to account for more than just fire suppression. Additional reserves may include:

• System Testing Allowance: Water used during monthly or annual system testing.
• Make-up Water Supply Time: If a refill source (well, city water) is available, tank size can be smaller with quick replenishment.
• Multiple Risk Zones: Facilities with separate fire zones may require separate volume calculations per zone.
• Redundancy Requirements: Some regulations or insurance companies require 100% redundancy (i.e., dual tanks or backup capacity).

Step 5: Consider the Type of Fire Protection System

Different systems require different tank configurations:

• Sprinkler Systems: Based on NFPA 13, sprinkler water demand is often 250–500 GPM for 60–90 minutes in commercial settings. For high-hazard areas, demands can exceed 1,000 GPM.
• Fire Hydrants: Typically require a fire flow of 1,000–2,000 GPM. Tank size must support this volume for the required duration.
• Combined Systems: For buildings with both sprinklers and hydrants, you must consider the higher flow or the combined demand, depending on fire code requirements.



Step 6: Account for Tank Configuration & Usable Volume

The tank's total capacity must include some buffer to account for:

• Dead volume at the bottom (inaccessible due to outlet placement)
• Sludge and sediment build-up
• Safety buffer (usually 5–10% extra)

Adjusted Formula:
Required Tank Capacity = (Fire Flow × Duration) + Buffer + Dead Volume

For example:
Calculated Volume = 60,000 gallons
Buffer (10%) = 6,000 gallons
Dead Volume = 2,000 gallons
Final Tank Size = 60,000 + 6,000 + 2,000 = 68,000 gallons



Step 7: Evaluate Site-Specific Constraints

In addition to technical calculations, consider:

• Available space: Vertical vs. horizontal tank orientation based on footprint.
• Water source availability: If refilling is possible from a well or main line, size may be reduced accordingly.
• Climate conditions: In freezing areas, tanks may require insulation or be underground.
• Tank materials: Choice of tank material (steel, fiberglass, concrete) affects configuration and total volume.



Step 8: Check Regulatory Approval & Certification

Once the preliminary design is done, submit your tank sizing and specifications to:

• Local fire marshal or fire authority
• Insurance providers (FM Global, etc.)
• Engineering consultants or certified fire safety inspectors

Ensure the tank design meets all relevant standards including:

• NFPA 22 – Water Tanks for Private Fire Protection
• AWWA D103 – Factory-Coated Bolted Steel Tanks
• ISO and EN fire safety standards (for international facilities)



Step 9: Optimize with Engineering Software or Consultant Support

While basic calculations provide a solid estimate, large-scale projects should leverage:

• Fire protection design software
• CFD (Computational Fluid Dynamics) models
• Hydraulic calculations
• Professional fire engineers

These tools ensure all factors are accounted for: pipe friction losses, pump pressure, refill rates, and backup scenarios.



Example Use Case

Logistics Warehouse

• Sprinkler demand: 750 GPM for 90 minutes
• Hydrant demand: 1,500 GPM for 60 minutes
• Fire code requires sizing based on combined peak flow

Total flow = 750 + 1,500 = 2,250 GPM
Duration = 60 minutes
Volume = 2,250 × 60 = 135,000 gallons
Add buffer (10%) = 13,500 gallons
Total = 148,500 gallons tank capacity recommended



Final Tips

• Always round up: Never undersize. A 10% oversize is better than falling short.
• Plan for maintenance: Consider how the tank will be drained, inspected, and cleaned.
• Include fire pumps: The tank is only part of the system. Pumps and controllers must match the tank’s delivery capabilities.
• Think future-proof: Leave room for future expansion or upgrades in tank size.



Conclusion

Sizing a fire water tank is more than just plugging numbers into a formula—it's about understanding your facility's unique fire risks, regulatory requirements, and operational needs. By following this structured approach, you can ensure that your fire protection system is both compliant and reliable when it matters most.

Whether you're managing a high-rise building, an industrial complex, or a remote power station, proper fire water tank capacity is a critical element of your fire safety strategy. Take the time to calculate it right—lives and assets may one day depend on it. If you would like more information about this product, please feel free to contact Wansheng!
